Make the project as unique as you like.
Express your creativity with Omega II UNIK perforated aluminum panels! Transform your sidewalks into a true artistic canvas by playing with
light, shadows, contrasts, and textures. Choose from our standard designs or create your own at no additional cost! Omega II UNIK: the key to creative spaces.
- Highly versatile system.
- Elegant way to screen required areas
- Secured by tamper proof hardware
- Select from our pattern library or request your own
- Maintenance-free
| Vertical Panel |
Standard Height |
91 3/4" (2330 mm) or 67 3/4" (1721 mm) |
| Standard length |
44" (1118 mm) |
| Material |
1/8" (3.18 mm) thick aluminum (Ask our representatives for other materials and thicknesses available.) |
| Finish |
Polyester powder coated |
| Hardware |
5/16" (8 mm) carriage bolts and tamper proof (tri-groove) nuts |
| Horizontal Panel |
Standard Height |
43 3/4" (1111 mm). Stackable |
| Standard length |
92" (2337 mm) or 68" (1727 mm) |
| Material |
1/8" (3.18 mm) thick aluminum (Ask our representatives for other materials and thicknesses available.) |
| Finish |
Polyester powder coated |
| Hardware |
5/16" (8 mm) carriage bolts and tamper proof (tri-groove) nuts |
| Square post |
Dimensions |
2" x 2" or 3" x 3" (50.8 x 50.8 mm or 76.2 x 76.2 mm) |
| Caps |
Standard Cap |
| Flat post |
Dimensions |
2 1/2" x 1/4" (63.5 x 6.35 mm) |
| Caps |
Flush (no caps) |
| Bolting |
Carriage Bolt 5/16" (8 mm) - Tamper Proof Nuts |
| Gap bottom panel/ground |
2" (50.8 mm) |
| Complexity |
The cost of our perforated panels is listed in order of complexity. A panel rated A is therefore less
expensive than a panel rated D, for which more cutting work is required. For more information,
please ask our customer service. |
| Technical Catalog |
Gate Hardware Guide |
3-Part specs |
|
|
|
| Horizontal panels |
Vertical panels |
|
|
| Single swing |
Double swing |
Single cantilever |
Double cantilever |
|
|
|
|
|
The cost of our perforated panels is listed in order of complexity. A panel rated A is therefore less expensive than a panel rated D, for which more cutting work is
required. For more information, please ask our customer service.
Choose from our standard and optional colors or hundreds of custom colors from the RAL selection.
Select light colors, such as white or yellow, and be
seen from a distance. Darker colors, such as brown or green, blend with the background.
Standard color
Optional colors (Additional charges will apply)
Signal white RAL 9003
Gloss
Silver Grey RAL 7001
Gloss
Basalt Grey RAL 7012
Gloss
Chocolate Brown RAL 8017
Gloss
Signal red RAL 3001
Gloss
Rust (±6 months)
Textured Corten Look
Dark Rust (±2 years)
Textured Corten Look
Signal Yellow RAL 1003
Textured
Saphire blue RAL 5003
Textured
